the fileTHATplaces your engine

the file that DEPLOYS you

You've been burned by a config file before. It started as ten honest keys — a name, a port, a region — and then someone needed "just one hook," and a year later it was a Turing-complete YAML pipeline with an exec: key, secret interpolation, and a templating language nobody chose. The word declarative was on the box. The contents were a program you couldn't read.

So when the parent lesson says "flip local to cloud and your prototype is the product," your reflex is right: that's a brochure line until proven otherwise. Every platform claims declarative deploys. The claim is only worth anything if you can audit it — read the whole reader in one sitting and confirm there's no place a program could hide.

That's the bar this page sets, and then clears. A deployment description you can hold in your head. Inert by construction, not by promise. We'll read the parser, watch the validator refuse to let you lie to yourself, and bring the same engine up on a laptop and on a public host — to show the "one property" claim cashes out as a measurable fact, not a vibe.

the DEFINITION

Two words in that definition carry the whole lesson. Converges: you describe the end state, the tooling makes reality match — no steps, no order, idempotent. Never executed: the file is read by a hand-rolled scan of the :PROPERTIES: drawer, not by the org engine that tangles and runs other workbooks. A deployment file is the one org file in the system that is pure config and nothing else — and that's a property you can verify, not a posture.

five axes, one SCREEN

Here is the real local deployment, shipped in the kit, whole. One headline, one drawer, seven lines of properties — this is not a fragment:

* local                                                      :deployment:
  :PROPERTIES:
  :ID:            local
  :ENGINE_PLACE:  local
  :TENANCY_MODE:  single
  :STORAGE:       local-fs
  :DATABASE:      sqlite
  :AUTH:          trusted
  :END:

Five of those properties are closed enums — the only axes that exist, each with a fixed set of legal values:

Everything else — APP, PROVIDER (defaults to fly), REGION, the storage endpoint and bucket, the auth issuer — is an open property: a string the relevant axis reads when it needs one. There is nothing else. No fifth verb hiding in a sixth key.

Now the part that earns the word "inert." The reader is about twenty lines. It walks the file top to bottom, flips a boolean when it sees :PROPERTIES: and flips it back at :END:, and inside the drawer it matches each line against one regular expression:

^:([A-Za-z_]+):\s+(.*\S)\s*$
        │              └─ the value, trimmed
        └─ the key, uppercased

A line that matches contributes a key and a value. A line that doesn't match is silently ignored. That's the whole parser. No interpolation, no ${}, no hooks, no template language, no branch where a string becomes code. "Declarative" here is a measurable property of a reader you could screenshot — not a marketing adjective. The reason your old config files rotted is that their readers grew teeth. This one can't, because there's nowhere for teeth to go.

the honesty ENGINE

A linter checks syntax. validate checks truth. It runs with zero deploy — read-only, no machine touched — and its job is to refuse configurations that would lie to you. Its error messages aren't style notes; they're distributed-systems tradeoffs encoded as refusals. Three of them are worth quoting verbatim, because each one is a lesson that would otherwise cost you a 2 a.m. page:

TENANCY_MODE: multi + DATABASE: sqlite  →  rejected:
  "multi on DATABASE: sqlite serializes every tenant
   through one writer — set DATABASE: postgres"

TENANCY_MODE: multi + AUTH: trusted  →  rejected:
  "`trusted` has no identity to isolate tenants by"

STORAGE: s3 + missing secrets  →  rejected:
  "STORAGE: s3 needs WB_S3_KEY + WB_S3_SECRET in your
   deploy ENV (secrets, not the file)"

Read what those refusals know. Multi-tenant on one SQLite writer doesn't fail — it works, slowly, funneling every tenant through a single lock until the day it doesn't, and the validator would rather you learn that now than in production. trusted auth has no token, no subject, no identity — so there is literally nothing to scope a tenant by, and "multi-tenant with trusted auth" isn't a configuration, it's a contradiction. And s3 demands its credentials from the environment, by name, because secrets in the file is the original sin and the validator won't be complicit in it.

The full set of checks, as a flow — enum legality first, then the combinations that can't coexist, then the secrets the chosen axes require:

flowchart TD
  cfg[["deployment.org"]] --> enums{"five axes
legal values?"}
  enums -- no --> bad["invalid — unknown value on an axis"]
  enums -- yes --> combo{"combinations
coherent?"}
  combo -- "multi + sqlite" --> bad2["one writer for every tenant"]
  combo -- "multi + trusted" --> bad3["no identity to isolate by"]
  combo -- ok --> sec{"required secrets
present in ENV?"}
  sec -- "s3, no WB_S3_KEY" --> bad4["secrets, not the file"]
  sec -- "postgres, no WB_DATABASE_URL" --> bad5["the DSN is a secret"]
  sec -- "real auth, no ISSUER" --> bad6["a token needs an issuer"]
  sec -- all present --> ok["valid — local · single-tenant
storage=local-fs · db=sqlite"]
  style cfg fill:#aee5c2,stroke:#121316,stroke-width:2.5px
  style ok fill:#13d943,stroke:#121316,stroke-width:2.5px
  style bad fill:#ffffff,stroke:#121316
  style bad2 fill:#ffffff,stroke:#121316
  style bad3 fill:#ffffff,stroke:#121316
  style bad4 fill:#ffffff,stroke:#121316
  style bad5 fill:#ffffff,stroke:#121316
  style bad6 fill:#ffffff,stroke:#121316


On success it prints the shape it understood — valid — local · single-tenant · storage=local-fs · db=sqlite — which is the same summary every verb speaks. Notice the deliberate split: postgres needs WB_DATABASE_URL ("the DSN is a secret"), s3 needs its endpoint and bucket in the file but its key and secret in the env, and any real auth needs an ISSUER — the origin a token is checked against. Two separate checks, two separate error strings, because they are two separate kinds of thing. The validator is the part of the system that refuses to let you write a config that would quietly lie.

a cloud on your DESK

Depth rung — skippable, but it's where "local isn't a simulator" becomes a fact you can run. Local place is not a mock. It's the same ghcr.io/workbooks-sh/runtime:latest OCI image cloud uses, booted in a real Linux microVM on your mac via libkrun and krunvm. The microVM is the outer isolation boundary — distinct from, and wrapped around, the wasm sandbox each workbook runs in. krunvm is the mac arm of a cross-platform seam; podman, docker, and WSL2 slot in behind the same ensure→create→run→status→down contract.

The bring-up, command by command, is shorter than the explanation:

$ wbx deploy doctor
created the case-sensitive APFS volume; prereqs OK now

$ wbx deploy apply
local runtime up — http://127.0.0.1:55123 (survives app quit; `wbx deploy down` to stop)

$ wbx deploy verify
runtime healthy — http://127.0.0.1:55123/health → 200

Under that calm output is a sequence with two real macOS war stories baked into it. First the one-time prereq: krunvm's OCI store needs a case-sensitive APFS volume, which doctor creates for you with diskutil apfs addVolume <disk> "Case-sensitive APFS" krunvm — no sudo, non-destructive, self-healing. Then the create, with flags that each exist for a reason:

krunvm create ghcr.io/workbooks-sh/runtime:latest \
  --name workbooks-runtime --cpus 2 --mem 2048 \
  --workdir /app \              ← krunvm won't inherit the image WORKDIR
  --port 55123:4000 \          ← free host port → guest's fixed 4000
  --volume …/data:/data \      ← your data, on the host
  --volume …/disco:/disco      ← the discovery handshake lands here

The boot command is the first war story. You'd expect bin/workbooks start — but the release's start runs a foreground console that needs a TTY, and under krunvm's no-TTY guest it blocks at console init before the app ever boots: silent, no discovery, nothing. So the boot is /app/bin/workbooks eval '…ensure_all_started… Process.sleep(:infinity)' — boot the app, then park forever; on failure System.halt(1) so it surfaces in wbx deploy logs instead of hanging.

sequenceDiagram
  participant U as wbx (your session)
  participant K as krunvm
  participant V as the microVM (the runtime image)
  participant D as /disco (bind mount)
  U->>K: doctor — APFS volume ready
  U->>K: create + start --env WB_DESKTOP=1 …
  K->>V: boot via `eval` (no TTY needed) → park
  V->>D: write runtime.json (port, pid, token)
  U->>D: poll up to 20s for runtime.json
  D-->>U: found — port + bearer token
  U->>V: GET http://127.0.0.1:55123/health (bearer)
  V-->>U: 200 · body contains "ok"


The second war story is why the VM survives you closing the app. libkrun needs the user's GUI session — run under a background LaunchAgent it exits 78 (EX_CONFIG). So the default lifecycle is a direct nohup-detached spawn into your Aqua session, with the pid in a pidfile: it survives the app quitting (reparented), and dies on logout. A LaunchAgent path exists for start-on-login, but it's the path that fights libkrun, so it's opt-in.

And the handshake itself: the runtime inside the VM writes /disco/runtime.json — port, pid, and a bearer token — into the bind-mounted directory, and the host reads it straight off the mount. That file is the local control-plane handshake. status and verify read it; verify uses the token to hit /health and expects a 200 with "ok" in the body. When you run down, both lifecycles are removed and the VM is deleted — but /data and the APFS volume are preserved. Your data outlives the machine.

five hooks and a TEMPFILE

Cloud isn't magic either. A provider is a directory: cli/deploy-kit/providers/<place>/bootstrap.sh. The place resolves to a backend — local resolves to the built-in Machine module, anything else resolves to that bootstrap script. Adding a provider is dropping a directory; the core never changes. Each recipe fills the same five hooks plus a lifecycle trio:

provider_ensure_app      ← create the app if missing
provider_set_secrets     ← stage credentials, out of band
provider_attach_volume   ← a persistent disk for /data
provider_deploy_image    ← run the OCI image
provider_public_url      ← print  url: https://…
  + provider_down / provider_status / provider_logs

The kit drives the script with an action — up runs those first five in order; down, status, logs, url do the obvious thing. The provider's exit code is honored all the way out to the CLI's exit code, so a failed host failure is a failed command.

flowchart TD
  apply["wbx deploy apply"] --> place{"ENGINE_PLACE?"}
  place -- local --> machine["built-in Machine
(krunvm microVM)"]
  place -- cloud --> recipe["resolve providers/<place>/bootstrap.sh"]
  recipe --> up["WB_RECIPE_ACTION=up"]
  up --> h1["ensure_app"] --> h2["set_secrets"] --> h3["attach_volume"] --> h4["deploy_image"] --> h5["public_url → url:"]
  style apply fill:#aee5c2,stroke:#121316,stroke-width:2.5px
  style machine fill:#ffffff,stroke:#121316
  style h5 fill:#13d943,stroke:#121316


Fly is the one bundled recipe — and the comment at the top of it says so plainly: Fly is our personal preference, not a privileged target, just one recipe behind the provider-neutral spine. Here's what makes it concrete. On apply, the Fly recipe creates the app if missing ("converge, don't complain"), stages secrets, creates a 1 GB volume wbdata if absent — then synthesizes a minimal fly.toml in a tempdir, deploys it, and deletes it:

app = "my-app"
primary_region = "sjc"

[build]
  image = "ghcr.io/workbooks-sh/runtime:latest"

[mounts]
  source = "wbdata"
  destination = "/data"

[http_service]
  internal_port = 4000
  force_https = true
  auto_stop_machines = "stop"
  auto_start_machines = true
  min_machines_running = 0

The public URL is https://my-app.fly.dev. And the env every provider forwards is the quiet keystone: WB_WEB=1, PORT=4000, WB_DATA=/data, and crucially WB_REGISTRY=/data/registry.db. The registry defaults to :memory: in the engine — pointing it at the volume is exactly what makes deployed workbooks survive a restart or a scale-to-zero, with litestream replicating that SQLite db. Those auto_stop_machines / min_machines_running = 0 lines are scale-to-zero; the volume + registry pointer is what keeps it safe.

The punchline is the contract's smallness. A Hetzner, Render, or AWS recipe is the same ~90 lines with different commands, because the engine asks the host for only four things: run my container, attach a volume, deliver my secrets, expose a port. Everything a PaaS does beyond that is the PaaS's business, not the engine's.

the actual DIFF

Now the parent's claim, made literal. Moving from local to cloud is editing ENGINE_PLACE — and then adding exactly the properties the validator forces you to add. Here is the diff against the shipped cloud SaaS deployment:

  * local                                  →  * cloud-saas              :deployment:
    :PROPERTIES:                                :PROPERTIES:
-   :ENGINE_PLACE:  local                  +   :ENGINE_PLACE:     cloud
+                                          +   :PROVIDER:         fly
+                                          +   :APP:              my-app
    :TENANCY_MODE:  single                 +   :TENANCY_MODE:     multi
-   :STORAGE:       local-fs               +   :STORAGE:          s3
+                                          +   :STORAGE_ENDPOINT: https://s3.us-east-1.amazonaws.com
+                                          +   :STORAGE_BUCKET:   my-bucket
+                                          +   :STORAGE_REGION:   us-east-1
-   :DATABASE:      sqlite                 +   :DATABASE:         postgres
-   :AUTH:          trusted                +   :AUTH:             clerk
+                                          +   :ISSUER:           https://my-tenant.clerk.accounts.dev
+                                          +   :REGION:           iad
    :END:                                      :END:

None of those additions are decoration — each one is the validator refusing a half-edit. Try to go to multi tenancy while still on sqlite and trusted, with s3 but no credentials, and validate stops you cold:

$ wbx deploy validate cloud-saas.org
invalid deployment:
  - TENANCY_MODE: multi on DATABASE: sqlite serializes every tenant
    through one writer — set DATABASE: postgres
  - STORAGE: s3 needs WB_S3_KEY + WB_S3_SECRET in your deploy ENV
    (secrets, not the file)

So you don't add postgres because a guide told you to — you add it because multi demanded it. The same translation runs in both directions, and it's one function — Config.to_env/1 — that turns the five axes into the engine's environment. Same keys, sourced differently per place:

The verdict of that table is the whole "one property" claim in one row: WB_IMAGE is identical on both sides. Same image, same env-assembly function, two delivery mechanisms. The JWKS path is the one bit of cleverness — BetterAuth's is non-standard (issuer + /api/auth/jwks), anything OIDC-ish is the well-known path (issuer + /.well-known/jwks.json), and an explicit JWKS_URL property overrides both. Beyond that, the diff is the deploy.

names in the file, values NOWHERE near it

Depth rung — skippable, but it's the discipline that lets the file stay inert and public. The doctrine is stated in the header of the file users read first: secrets are not in this file. Axes live in the drawer; credentials live in your deploy environment. The validator enforces it from the other side, and the translator forwards secret values from the env without ever echoing them.

The richer flow, in the Rust kit: you declare secrets by name in the file with #+DEPLOY_SECRETS: KEY …, set values with wbx deploy secrets set KEY=VALUE (stored mode-0600 in secrets.env under the app dir), and list them by name only — secrets list never prints a value. Locally they're delivered as --env-file; in the cloud they're staged through the provider's set_secrets hook. Values never enter deployment.org or any image. And apply refuses to deploy with a declared secret unset — it tells you which one and how to set it.

flowchart LR
  v["a secret's value"] --> store["env  /  secrets.env (0600)"]
  store --> recipe["recipe env (in memory)"]
  recipe --> stage["fly secrets set --stage"]
  stage --> ctr["container env"]
  org[["deployment.org
(declares the NAME only)"]] -. "never touched" .-> ctr
  style org fill:#aee5c2,stroke:#121316,stroke-width:2.5px
  style ctr fill:#13d943,stroke:#121316


The graph's point is the dotted line: the value travels env → recipe → staged secret → container, and deployment.org sits off to the side, naming the key and touching the value never.

Two secrets earn special handling because they are your engine's identity. On the first cloud apply, the kit generates WB_PUBLIC_BEARER — 32 random bytes, hex — exactly once, persists it, and never rotates it. Rotating it would 401 every live client and break the tenant's stable identity; the kit prints control-plane locked — export WB_ENGINE_TOKEN=<token> and means it. And WB_SIGNING_KEY — a 32-byte Ed25519 seed — is the engine's DID: set it once (generate with one line of Elixir) and your engine's identity survives every redeploy. Skip it and the DID regenerates on each deploy, and every prior signature and ledger entry stops verifying. Tenant scoping, finally, is enforced above the storage backend on purpose — so swapping S3 for R2 can't widen access.

converge, prove, TEAR down

The verbs are built for agents as much as humans: every one is non-interactive, idempotent, takes --json, and exits non-zero on failure. The arc is init → validate → apply → status|verify|logs → down, with two shortcuts: wbx deploy local for the zero-config bring-up (think docker run) and wbx deploy doctor to check and self-heal prereqs.

Two rows carry the weight. verify doesn't trust the deploy log — it proves the live engine: locally it reads the discovery file and hits http://127.0.0.1:<port>/health with the discovery bearer token, expecting a 200 with "ok"; in the cloud it asks the provider recipe for its URL, then hits <url>/health. And doctor doesn't just diagnose — if the APFS volume is missing it creates it and reports the system is now ready. The contract — non-zero exit on failure, JSON on request — is what lets a workflow run the whole arc unattended and a human run it by hand, from the same surface.

where the seam ENDS

Honesty section. The macOS path carries real, un-pretty engineering. The TTY boot hack and the EX_CONFIG/Aqua-session requirement aren't elegance — they're scars, the direct-spawn VM dies on logout, and the LaunchAgent path that would survive login conflicts with libkrun. The default lifecycle is the one that works, not the one that's tidy.

The cloud side ships exactly one recipe: Fly. The seam is provider-neutral by design and any host fits the five hooks, but "any host" is a promise about the contract, not a directory of pre-written recipes — today you'd write the Hetzner one yourself. The Rust kit's krunvm lane also can't deliver the kit's secrets env yet, so if you stage kit secrets locally it tells you to use docker or podman instead.

There is no fleet story. One deployment.org is one machine. No regions array, no blue-green, no rolling orchestration — convergence is per-file, and scale beyond a single machine is out of this lesson's scope and out of the tooling's current scope. We'd rather say that than imply a control plane that isn't there.

And there are, in transition, two CLI dialects: the :PROPERTIES: drawer with ENGINE_PLACE (taught here, used by the shipped examples and the parent lesson) and an older #+DEPLOY_* keyword form the Rust binary's templates still emit. Teach yourself the drawer form — it's the canon — and treat the other as drift to be normalized, not a second thing to learn.
