write a lineSEEthe row

folklore vs GRAMMAR

Org-mode the Emacs thing is twenty years deep. Agenda views, footnotes, clock tables, capture templates, link abbreviations, column views — a folklore so large that no two org users have ever met who used the same tenth of it. Read its manual and you will learn a hundred constructs. Read this ecosystem's parser and you will learn that it honors maybe a dozen.

That gap is the whole problem this page exists to close. A spec tells you what a feature is supposed to do; specs are aspirational, and they lie by omission about what a given implementation actually reads. The kernel here is not org-mode — it's an opinionated lens pointed at org text, and it surfaces exactly the lines that carry meaning to the rest of the system. Every other line is rendered as prose and otherwise ignored.

So we won't learn grammar from a spec. We'll learn it from the parser itself: write a line, run it through the kernel, read the JSON it hands back. A construct that produces a field is grammar here. A construct that vanishes is folklore. The parser is the only authority that never lies, because it's the thing the system actually runs.

the DEFINITION

The headline is the unit. Parse any org file and the kernel returns one row per headline, and every row has exactly these eight keys — no more, no fewer:

Eight fields. That's the entire contract for a headline, and it's small enough to hold in your head precisely because the kernel is opinionated. The grammar isn't small by accident — it's small by design, so that what one human writes, another human and every agent read the same way.

the DRILL loop

Here's the method for the whole page, and the method you'll keep after it. Pipe org text into the kernel through the CLI and read the rows it returns:

printf '* TODO water the plants  :home:\n' > task.org
wbx query task.org

Point wbx query at any .org file and it calls the kernel's parse_headlines and prints the JSON array. There's no project, no config, no setup — the kernel is a pure function from text to rows. The same text, the same row, every time, on any of the kernel's surfaces. The flow is exactly this:

flowchart LR
  org["org text
(one line or a whole file)"]
  subgraph kernel["the OQL kernel — one pure function"]
    parse["orgize parse"] --> lens["the lens
(keep 8 fields, drop the rest)"]
  end
  org --> kernel
  kernel --> rows["JSON rows
[{level,title,state,…}]"]
  style kernel fill:#fbfaf6,stroke:#121316
  style rows fill:#f2ddb0,stroke:#121316,stroke-width:2.5px


Two stages, and the second is the one that matters. First the parser (orgize, an off-the-shelf Rust library) reads the org tree. Then the lens walks that tree and keeps only what the system cares about — the eight headline fields, source blocks, the workflow tags — and lets everything else fall through as prose. Every example below this line is real output from that function. Nothing is illustrative; each cell was machine-verified. You can reproduce any of them by saving the org and running wbx query on it.

anatomy of one LINE

A headline is positional. Read left to right, each region is a different field. Here is the most a single headline can carry, annotated:

*      ← stars → level (here: 1)
TODO   ← state keyword (TODO or DONE only)
[#A]  ← priority cookie — silently swallowed, no field
rotate signing key   ← title
:ops:security:       ← trailing tag run → tags

All on one line, that's * TODO [#A] rotate signing key :ops:security:, and it parses to a row where level is 1, state is "TODO", title is "rotate signing key" — clean, cookie gone — and tags is ["ops","security"]. The tags are stripped off the end of the title for you; the title comes back without them.

The edges are where confidence is won or lost, so drill them. These are all verified:

• A headline needs a star at column zero and a space after it. *no space is not a headline — it vanishes from the rows entirely. An indented  * star is not a headline either — also gone. Column zero, then a space. Nothing else counts.
• Tags can't contain spaces. :ops:security: is two tags. :a b: is not a tag at all — it stays in the title as literal text, because the tag scanner only accepts a colon-run with no internal spaces.
• The priority cookie has no field. [#A] is real org-mode syntax and orgize swallows it cleanly — the title comes back without it — but the kernel exposes no priority key anywhere on the row. If you lean on priorities, the lens does not see them. Honest limit.

the ONE-line rule

This is the single gotcha most likely to bite you, so it gets its own section. The planning line — the SCHEDULED: and DEADLINE: stamps — must sit on the one line directly under the headline, together. Split them across two lines and the parse quietly falls apart, and not just for the planning fields.

Here is the broken form and the fixed form, same content, side by side. The difference is one newline:

The failure cascades — the second planning line poisons the drawer that comes after it. So your owner property, your ID, your whole record evaporates to {} because of a stray newline two lines up. There's no error; the row just comes back hollow. When a drawer mysteriously parses to nothing, this is the first place to look. One line. Always one line.

headline as RECORD

A :PROPERTIES: drawer turns a headline into a typed record. Two rules carry most of the surprises, both verified:

So :owner: becomes OWNER — the key you read in the JSON is never the key you typed, casing-wise. And :ID: appears twice: once inside props like every property, and once promoted to the top-level id field, because the system asks "what is this headline's identity?" often enough to earn the shortcut. This section is deliberately short — the drawers deep dive takes the property mechanism all the way down to toolkit manifests and agent identities.

the CLOCK glyphs

Depth rung — skippable, and the timestamps deep dive goes the whole distance. But the shape is worth seeing once. The brackets decide whether a timestamp is active:

Angle brackets mean active:true — this is a thing the engine should act on. Square brackets mean active:false — a record of when something happened, inert. The parser is loose by design: the date is just whichever token is ten characters long with a dash at position four; the time is the first token with a colon; the repeater is a token starting +, .+, or ++. Day names like Sat are skipped, never validated — write Xyz and it shrugs.

One honest leak to know now: a time range passes through raw. <2026-06-20 Sat 09:00-10:30> yields "at":"2026-06-20T09:00-10:30" — the whole range token lands in the time slot. The lens doesn't split it; it just hands you the string. Useful to know before you parse at as a single time downstream.

blocks that COMPILE

Depth rung — the tangling deep dive is where this becomes a build system. The mechanic: a headline's section can carry a source block, and the kernel captures the first one only — its language, its header args, and its body. The header-arg grammar is six keys: :deps (comma-split list), :uses, :in, :out, :persist (a bare flag), and :dir. Anything else is silently ignored.

The interesting part is what happens when you tag two headlines as workflow and components. The kernel infers the data-flow edge by matching one component's :out to another's :in. Watch a two-step plan become a running world:

* etl                       :workflow:
  :PROPERTIES:
  :SCHEDULE: 0 6 * * *
  :END:
** fetch                    :component:
   #+begin_src js :uses http :out prices.json
   export async function run() { return fetch_prices(); }
   #+end_src
** report                   :component:
   #+begin_src python :deps pandas :in prices.json :out report.html :persist
   build_report()
   #+end_src

Run that through wbx tangle and the kernel computes — nobody draws — this:

flowchart LR
  subgraph plan["etl  :workflow:  · schedule 0 6 * * *"]
    fetch["fetch  :component:
uses: http · out: prices.json"]
    report["report  :component:
in: prices.json · out: report.html · persist"]
  end
  plan -- "kernel: tangle_plan()" --> world
  subgraph world["the compiled world"]
    f2["fetch"] -- "prices.json" --> r2["report"]
    imp["imports: http"]
    exp["exports: report.html"]
  end
  style plan fill:#fbfaf6,stroke:#121316
  style world fill:#fbfaf6,stroke:#121316
  style exp fill:#13d943,stroke:#121316


The output carries "edges":[{"from":"fetch","to":"report"}] — inferred purely because fetch's :out prices.json matched report's :in prices.json. imports is ["http"] (the deduped :uses), exports is ["report.html"] (the out nobody consumed), report carries "persist":true, and the :SCHEDULE: property surfaces as {"cron":"0 6 * * *"}. Two tagged headlines, and you have a scheduled, capability-aware build graph.

Now delete fetch and run wbx lint:

[{"level":"error","scope":"report",
  "message":"input `prices.json` has no upstream producer"}]

The validator flags exactly two kinds of error — a component with no source block or language, and an :in with no upstream producer. That's a syntax error that is also a plan error: report wants an input that nothing makes. This is the bridge to the workflows lessons — the same grammar that lists your to-dos also type-checks your build.

the AUTOPSY

The parent lesson argued that markdown can't see structure. Here's the receipt. Take that same rotate-key task and write it the way a careful person writes markdown — heading, bold labels, a sentence of metadata:

# TODO rotate signing key
**Scheduled:** 2026-06-20, repeat weekly. Tags: ops, security.

Run it through the very same kernel and you get:

[]

Zero rows. Not a degraded parse — nothing. Every fact a human reads in that markdown — it's a task, it's a TODO, it's scheduled, it repeats weekly, it's tagged ops and security — is invisible to the machine. A # heading is not a * headline; bold text is not a state keyword; a prose sentence is not a property drawer. The information is all there, perfectly legible to you, and the parser sees an empty array.

That's the whole why-not-markdown argument compressed into one command. Markdown is a format for documents you render. Org, through this lens, is a format for structure you compute on. Same characters on the page; one of them the kernel can answer questions about.

dissect the EASTER egg

The parent page hides a comment in its own HTML source — a note for whoever views the page the honest way. It isn't decoration; it's valid org, and it parses to a real row. Here's the row the kernel returns for it:

{"title":"you found the written layer",
 "tags":["easter","egg"],
 "props":{"DISCOVERED":"by viewing source, the honest way"},
 "level":1, "state":null, "id":null,
 "scheduled":null, "deadline":null}

The title is clean, the trailing :easter:egg: became tags, and a :DISCOVERED: property became DISCOVERED in props — the same uppercasing rule from the drawers section, proving itself on a comment nobody was supposed to find. The lesson inside the lesson: org lives anywhere plain text lives. View-source on the parent is itself the drill — paste that comment into wbx query and you'll get exactly the row above. (This page hides one too. Go look.)

where the lens STOPS

Honesty section. The kernel is a lens, not org-mode, and a lens has edges. Knowing them is the difference between trusting the grammar and being surprised by it:

That last row is the honest summary of the whole page. Most of org-mode's enormous surface still renders — the kernel's render() is just orgize's to_html(), so footnotes and tables and links all come out as fine HTML. They just don't become structure the system computes on. The lens surfaces what the ecosystem needs to be machine-readable, and renders the rest as the document it is. That's not a missing feature; it's the line between structure and prose, drawn on purpose.
