one binaryKNOWSwho's listening

the tool that hangs in CI

Everyone has been burned by the same command-line tool. It runs fine on your laptop. You wire it into a CI job, and the build sits there for twenty minutes — silently, at a y/n prompt nobody will ever answer. You fix that, and now your logs are full of ANSI escape codes, because the tool tried to paint you a color table the log viewer can't read. And when something finally fails, it exits 1 — for everything, always — with a paragraph of prose you have to grep to find out why.

The industry's usual answer is to ship two things: a CLI for humans and an SDK or HTTP API for machines. They start aligned and drift apart — the flag the CLI grew last week isn't in the SDK, the error the SDK returns isn't the one the CLI prints. An ecosystem with one tool — one binary on the laptop, in CI, and inside the engine — can't take that fork. It needs the single command to be safe for an agent and pleasant for a person without becoming two programs that disagree.

wbx solves this with manners, not forks. The work is one code path; the audience is decided once, at the very end. The SPEC is candid about where this started: before the mode model, wbx had zero interactivity — accidentally agent-safe, deliberately human-poor; errors were plain strings with exit code 1 for everything; no --json anywhere; no color. The fix wasn't a rewrite. It was a seam.

the DEFINITION

It's a single enum — Mode { Human, Agent, Json } — and the SPEC's framing for it is exactly four ideas long: one switch, three ways to set it, sensible default. The guiding rule underneath is that human mode should be dumb-simple — the tool does the work, and a learning curve is treated as a bug. The same instinct, pointed the other way, is what makes the machine modes trustworthy.

eleven lines that DECIDE

The whole human/agent split begins in one function, detect, and the order of its checks is the entire contract. Read it top to bottom — the first match wins:

flowchart TB
  start(["wbx verb runs"]) --> j{"--json passed?"}
  j -- yes --> J["Json — the envelope"]
  j -- no --> a{"--agent, or
WBX_AGENT=1 ?"}
  a -- yes --> A["Agent — plain text, no prompts"]
  a -- no --> t{"stdout is a terminal?
is_terminal()"}
  t -- yes --> H["Human — landing, color, prompts"]
  t -- no --> A2["Agent — the safe default"]
  style J fill:#a8d4f0,stroke:#121316
  style A fill:#d9dbd3,stroke:#121316
  style A2 fill:#d9dbd3,stroke:#121316
  style H fill:#aee5c2,stroke:#121316
  style start fill:#ffffff,stroke:#121316


The precedence is --json first, then --agent or WBX_AGENT=1, then the terminal test, and if none of those fire — piped, redirected, no TTY — the fallback is Agent. That last choice is the important one. When wbx can't tell who's listening, it does not assume a human is there to answer a prompt. The safe failure for an unknown caller is silence and plain text, never a hang. A pipe is agent-by-default precisely because a pipe might be a CI runner with no keyboard attached.

The terminal test is std::io::IsTerminal — standard library, no crate, one call on stdout(). The two flags are global clap arguments: --agent forces agent mode (never prompts, no ANSI), and --json is agent mode plus a single JSON envelope on stdout. And one honest nit worth stating plainly: WBX_AGENT must be exactly the string 1. WBX_AGENT=true does nothing — the check is a literal v == "1". Set it to 1 or don't set it.

One verb, three manners, live:

$ wbx status                # TTY → human: landing + a start-here verb menu
$ wbx status | cat          # piped → agent: structured body, no menu, no color
$ WBX_AGENT=1 wbx status    # agent manners ON a terminal
$ wbx --json status         # the envelope: {"ok":true,"verb":"status","data":{…}}

The agent landing has a small extra kindness: it splices the whole verb tree into the doctor body. One call, and an agent knows both the system's health and its entire surface.

one channel, rendered ONCE

Detection is cheap because of a discipline upstream of it: every command in wbx returns a single String, and main is the only thing that renders. The shape of main is small enough to hold in your head:

let m = mode::detect(cli.json, cli.agent);
let verb = mode::verb_path();
match run(cli, m == Mode::Human) {
    Ok(out) => render_ok(m, &verb, &out),
    Err(e)  => exit(render_err(m, &verb, &e)),
}

That's the seam. The SPEC calls it one output channel — good, and credits it with making the entire mode model a mechanical refactor rather than a rewrite. Because the verb already produced one string, adding three manners meant adding one renderer at the exit, not editing every command.

sequenceDiagram
  participant U as you / agent
  participant C as clap (parse + verb)
  participant R as run() — one verb
  participant M as mode::render
  U->>C: wbx toolkit audit --json
  C->>R: dispatch
  R-->>M: Ok(String)  /  Err(anyhow)
  Note over M: detect() chose the mode
render_ok / render_err runs ONCE
  M-->>U: stdout (text or envelope)
  M-->>U: stderr (hint, if human)
  M-->>U: exit code


The story of that diagram: you or an agent type one command; clap parses it and picks the verb; run() does the real work and hands back either an Ok(String) or an error; then — and only then — the mode layer renders that result exactly once, sending output to stdout, any hint to stderr, and setting the exit code. Nothing branches on audience until that final box.

Two supporting details. First, verb_path() rebuilds the verb name for the envelope straight from std::env::args(): it skips flags, takes the first real word, and for group verbs — publish, toolkit, workflow, agent, workbook, deploy (a real constant) — it reaches in for the sub-verb too. So the envelope reports "toolkit audit", not just "toolkit"; there is a test that pins exactly that string. Second, the commands that genuinely need to render different content per audience — like doctor — take a human: bool and shape their data accordingly: prose for people, a structured body for agents. Everything else is identical work, spoken three ways.

one shape for every OUTCOME

In Json mode, success and failure share a single, predictable skeleton — the thing a script parses once and trusts forever. Success is { ok: true, verb, data }; failure is { ok: false, verb, error: { code, message, hint, retryable } }. Here is a real failure, no engine reachable:

$ WBX_ENGINE_URL=http://127.0.0.1:1 wbx --json rt status
{"ok":false,"verb":"rt status","error":{"code":3,
  "message":"…tcp connect error 127.0.0.1:1…",
  "hint":"no engine reachable — start one with `wbx deploy local` or set WB_ENGINE_URL",
  "retryable":true}}
$ echo $?
3

Three things in that envelope earn a closer look. The data field is embedded structurally when it can be: render_ok tries to parse the command's output as JSON, and if the command already produced JSON, it nests it as real structure; only if it's plain text does it wrap it as { "text": out }. You never get JSON-inside-a-string when real JSON was available. The retryable flag is computed, not hand-set — it's true exactly when the code is EXIT_ENGINE (3) or EXIT_CONFLICT (6), the two failures a retry can plausibly fix. And note where the envelope rides: even on failure it goes to stdout, not stderr — because in Json mode the envelope is the answer, success or not. (In Human and Agent mode, errors still go to stderr the normal way; the stdout-failure rule is specific to the envelope.)

classify, the honest HEURISTIC

A depth-rung — skippable on a first read, essential if you're writing the retry loop.

The exit codes are a small, fixed set: 0 for ok; 2 for a usage error (owned by clap, not by wbx — there's a test pinning that); and a handful of typed failures — EXIT_ENGINE=3, EXIT_NOT_FOUND=4, EXIT_VERIFY=5, EXIT_CONFLICT=6, EXIT_AUTH=7. Everything that doesn't match a category falls to 1, the catch-all.

How does a code get chosen? Today, by classify() — and the source is refreshingly blunt about what it is: a heuristic over the lowercased text of the error chain, until errors carry typed codes; the contract is the code, not the text. That sentence is the most important thing on this page for a script author. You branch on the number. You never parse the message. The string matching is an implementation detail on its way to being replaced; the code is the promise.

The verdict of that table: each failure class names the command that fixes it, and the two highlighted rows — 3 and 6 — are the ones retryable marks true. A 4 means enumerate what exists; a 5 means re-sign; a 7 means fix your token and never retry blindly. This is different from the broader what-a-script-should-do table on the parent page — that one stays there; this one shows the seam underneath it.

manners vs FORMAT

This is the page's sharpest distinction, and the one most people get wrong. Piping wbx does not give you the JSON envelope. A pipe selects Agent mode, which is manners — no prompts, no color, plain text. The envelope is a format, and you get it only by asking: --json. Agent mode is how wbx behaves; Json mode is what it emits. There is a contract test whose entire job is to prove that a piped command's output does not start with {"ok".

The hint routing in that table is the subtle part. The hint is for whoever can act on it, in the channel they actually read. A human gets it on stderr, right under the error, where their eyes already are. An agent in plain mode gets only wbx: {err} — no hint line, because plain agent output is for piping, not advising. And Json mode carries the hint structurally, so the consumer that parses the envelope can act on it programmatically. Same hint, three deliveries — or none, when none would be noise.

what only humans GET

A depth-rung — the two features that live entirely behind the mode gate.

Some things are luxuries a machine must never reach. wbx keeps two of them, and both are gated so hard that agent mode literally cannot trip over them.

The first is pick() — a hand-rolled picker that prints its menu to stderr and reads one line from stdin. Its doc comment is a warning to future maintainers: HUMAN mode only — callers must gate on mode; agent mode never reaches this. It has exactly one real call site, wbx deploy init run bare on a terminal, which asks where the engine should live:

? engine place — where does this run?
  › 1) local      a container on this machine — cloud-identical
    2) cloud      fly.io, under your own account
  [1]

Pipe that same command with stdin closed and there is no hang — it instantly takes the local default, writes deployment.org, and answers: wrote deployment.org (local) — edit it, then `wbx deploy apply`. The gate is enforced twice over: on a non-TTY the picker is never called, and the wasm32 build of pick() always returns the default no matter what — the in-sandbox wbx physically cannot prompt.

The second luxury is next_hint() — verb chaining, printed to stderr as → next: …, human only. After a successful deploy init on a terminal, the output grows a tail an agent never sees: → next: wbx deploy apply (converge to what you declared). The chains are short and real: build → bundle → sign → (verify or workbook deploy); deploy init → apply → status/logs; toolkit build → push; workbook deploy → list.

flowchart LR
  b["build"] --> bu["bundle"] --> s["sign"] --> v["verify"]
  s --> wd["workbook deploy"]
  di["deploy init"] --> ap["apply"] --> st["status / logs"]
  style b fill:#aee5c2,stroke:#121316
  style di fill:#aee5c2,stroke:#121316


Read that left to right as a human's guided path: finish a build and wbx whispers now bundle; bundle and it says now sign; sign and it offers two ways forward — verify it, or deploy the workbook. Init a deploy and the chain points you to apply, then to status and logs. An agent gets none of this, and wants none of it — it already knows where it's going.

the contract is a TEST suite

None of this is documentation-only. Every promise on this page has an assertion behind it in cli/tests/mode.rs. That file is the real contract; the prose here is a tour of it.

The verdict of that table: the most agent-hostile failure modes — a hang on a closed stdin, an envelope that disagrees with its own exit code, a pipe that vomits JSON you didn't ask for — are each a named, failing-if-broken test. The never-prompts test is the strongest: it runs wbx deploy init with stdin set to Stdio::null(), asserts the command succeeds, and asserts deployment.org exists on disk afterward. Closed stdin, no hang, file written — proven, not promised.

Two more worth naming because they shape everyday use. doctor always exits 0, even with no engine reachable — a health check must not fail the shell, and a test enforces it. And the author verbs accept - for stdin: echo "* hello" | wbx lint - returns [], which is the seam the sibling pipelines lesson is built on.

where the seam is HONEST

The mode model is small and tested, but it isn't finished, and pretending otherwise would undercut the whole point of a contract. Five honest edges:

• classify is string-matching, for now. Codes are derived from the text of the error chain. Typed error codes are the future; the code is the contract today, and that's exactly why you branch on the number and never on the message.
• exit 2 belongs to clap. Usage errors are emitted by the argument parser, not by classify() — a proven, deliberate boundary.
• 1 is the catch-all. Anything that doesn't match a typed category lands on 1. Treat it as unknown, not as a specific failure.
• WBX_AGENT must be exactly 1. Not true, not yes — the literal string 1.
• the failure envelope rides stdout. In Json mode, errors don't go to stderr — the envelope does, on stdout, so a single parse covers both outcomes.

One thing we won't claim: whether Human mode paints color and tables today. The SPEC promises that DX — color, tables, pickers, a landing — and the pickers and landing are real and tested. The color we won't overstate. What we will stand behind, fully, is the inverse and tested half of the contract: agent mode emits no ANSI, ever. That's the half a script depends on, and that half is law.
